Class: cruiser
Production: 1996-2017
Also called: Yamaha Drag Star 400
Related:Yamaha XVS650 Drag Star / V-Star
Predecessor:Yamaha XV400 Virago
Models | |
---|---|
Yamaha XVS400 Drag Star (Japan) 1996-2017 | Yamaha XVS400 Drag Star Classic (Japan) 1998-2017 |
Yamaha Drag Star 400 | Yamaha Drag Star 400 Classic |
History
History | ||
---|---|---|
Year | Country | Name / Frame / Engine |
1996 | Japan | Name: Yamaha Drag Star 400 Code: 4TR1, 4TR2 |
1997 | Japan | Name: Yamaha Drag Star 400 Code: 4TR3, 4TR4 |
1998 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 4TR6; 4TR5, 4TR7 |
1999 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 4TR8; 4TR9 |
2000 | Japan | Name: Yamaha Drag Star 400 Code: 5KP1, 5KP2 |
2001 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 5KP4, 5KP3 |
2002 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 5KP7, 5KP6 |
2003 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 5KP8, 5KPA |
2004 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 5KPB, 5KP9 |
2005 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 5KPC, 5KPD |
2006 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 5KPE; 5KPF, 5KPG |
2007 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 5KPH, 5KPK; 5KPJ |
2008 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 5KPL, 5KPM; 5KPN, 5KPP |
2010 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 35C2; 35C1, 35C3 |
2012 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 35C4; 35C5 |
2014 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 35C8; 35C7 |
2016 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 35CA; 35C9 |
2017 | Japan | Name: Yamaha Drag Star 400; Yamaha Drag Star 400 Classic Code: 35CC; 35CB, 35CD |
Specifications
Yamaha XVS400 Drag Star: specs
Mikuni Bds28 Diagram
Specifications | ||
---|---|---|
DIMENSIONS | Overall length | 2340 mm / 92,1 in – Drag Star 400 2450 mm / 96,4 in – Drag Star 400 Classic |
Overall width | 845 mm / 33,3 in – Drag Star 400 (1996-1999) 840 mm / 33,1 in – Drag Star 400 (2000-2017) 930 mm / 36,6 in – Drag Star 400 Classic | |
Overall height | 1045 mm / 41,1 in – Drag Star 400 (1996-1999) 1060 mm / 41,7 in – Drag Star 400 (2000-2006) 1065 mm / 41,9 in – Drag Star 400 (2007-2017) 1105 mm / 43,5 in – Drag Star 400 Classic (1998-2006) 1110 mm / 43,7 in – Drag Star 400 Classic (2007-2017) | |
Seat height | 660 mm / 26,0 in – Drag Star 400 710 mm / 27,9 in – Drag Star 400 Classic (1998-1999, 2003-2017) 712 mm / 28,0 in – Drag Star 400 Classic (2000-2002) | |
Wheelbase | 1610 mm /63,4 in – Drag Star 400 1625 mm / 64,0 in – Drag Star 400 Classic | |
Ground clearance | 140 mm / 5,5 in – Drag Star 400 145 mm / 5,7 in – Drag Star 400 Classic | |
Dry weight | 204 kg / 450 lbs – Drag Star 400 (1996-1999) 209 kg / 461 lbs – Drag Star 400 (2000-2008) 222 kg / 489 lbs – Drag Star 400 Classic (1998-1999) 224 kg / 494 lbs – Drag Star 400 Classic (2000-2008) | |
Curb (wet) weight | 220 kg / 485 lbs – Drag Star 400 (1996-1999) 225 kg / 496 lbs – Drag Star 400 (2000-2008) 234 kg / 516 lbs – Drag Star 400 (2009-2017) 238 kg / 525 lbs – Drag Star 400 Classic (1998-1999) 240 kg / 529 lbs – Drag Star 400 Classic (2000-2008) 247 kg / 544 lbs – Drag Star 400 Classic (2009-2017) | |
FRAME | Type | Double cradle (steel) |
Front suspension, travel | Telescopic fork, 140 mm / 5,5 in | |
Rear suspension, travel | Swingarm with mono-shock, 86 mm / 3,4 in | |
Front tire size | 100/90-19M/C 57S – Drag Star 400 130/90-16M/C 67S – Drag Star 400 Classic | |
Rear tire size | 170/80-15M/C 77S | |
Front brake | Single disc, 298 mm, 2-piston caliper | |
Rear brake | Drum | |
Fuel capacity | 15,0 l / 3,96 US gal | |
Trail | 153 mm / 6,02 in – Drag Star 400 145 mm / 5,71 in – Drag Star 400 Classic | |
Fuel economy / consumption | 2,28 l / 100 km (60 km/h) – Drag Star 400 2,63 l / 100 km (60 km/h) – Drag Star 400 Classic | |
ENGINE | Type | Air-cooled 4-stroke |
Cylinder arrangement | 2-cylinders V-type | |
Bore & Stroke | 68,0 x 55,0 mm | |
Displacement | 399 cm³ (24,3 cu in) | |
Compression ratio | 9.7:1 | |
Valve train | Chain driven SOHC, 2 valves per cylinder | |
Max. power | 33,0 hp (24,3 kW) / 7500 rpm – XVS400 (1996-2009) 30,0 hp (22,0 kW) / 7500 rpm – XVS400 (2010-2017) | |
Max. torque | 32,0 Nm (3,3 kg-m) / 6000 rpm – XVS400 (1996-2009) 31,0 Nm (3,2 kg-m) / 6250 rpm – XVS400 (2010-2017) | |
Acceleration 0 to 100 km/h (0-60 mph) | 11,2 sec. | |
Top speed | 135 km/h (84 mph) | |
CARBURETION SYSTEM | Type | Carburetor, 2x Mikuni BDS28 – XVS400 (1996-2009) Fuel injection, 2x – XVS400 (2010-2017) |
ID | ||
DRIVE TRAIN | Clutch | Wet, multi-plate, cable operated |
Transmission | 5-speed | |
Final drive | Shaft | |
Primary reduction | 2.028 | |
Final reduction | ||
Gear ratio I II III IV V |
1.900 1.458 1.167 0.967 | |
ELECTRICAL | Ignition | TCI (digital) |
Alternator | A.C. magneto | |
Battery capacity | 12V-8.6Ah |
